ACE RD658

Spares

Rock drill spares

1.Protective Nut

ACE Part No OEM REFF NO
251010 3100 9643 01
Rock drill spares

2.Seal Washer - Large

ACE Part No OEM REFF NO
251015 3101 4146 00
Rock drill spares

3.Adopter

ACE Part No OEM REFF NO
251020 3100 9623 01
Rock drill spares

4.Seal Washer - Small

ACE Part No OEM REFF NO
251025 3000 9341 02
Rock drill spares

5.Rubber Packing

ACE Part No OEM REFF NO
251030 3121 0336 00
Rock drill spares

6.Air Tube

ACE Part No OEM REFF NO
251035 3121 0352 00
Rock drill spares

7.Handle Bolt

ACE Part No OEM REFF NO
251040 3121 0360 00
Rock drill spares

8.Rubber Grip Set

ACE Part No OEM REFF NO
251045 3101 1372 00
Rock drill spares

9.Washer

ACE Part No OEM REFF NO
251050 3115 0574 00
Rock drill spares

10.Dome Nut

ACE Part No OEM REFF NO
251055 3121 0292 00
Rock drill spares

11.Side Bolt

ACE Part No OEM REFF NO
251060 3121 0343 00
Rock drill spares

12.Bracket Set ( L.H & R.H.)

ACE Part No OEM REFF NO
251065 -
Rock drill spares

13.Lever Handle Top

ACE Part No OEM REFF NO
251070 3115 0573 00
Rock drill spares

14.O-Ring

ACE Part No OEM REFF NO
251075 0663 2128 00
Rock drill spares

15.Lock Washer

ACE Part No OEM REFF NO
251080 3121 0332 00
Rock drill spares

16.Throttle Valve Spring

ACE Part No OEM REFF NO
251085 3121 5000 51
Rock drill spares

17.Throttle Pin

ACE Part No OEM REFF NO
251090 3121 0329 00
Rock drill spares

18.Wing Nut

ACE Part No OEM REFF NO
251095 9000 0333 00
Rock drill spares

19.Air Bend Pipe

ACE Part No OEM REFF NO
251100 3115 1170 00
Rock drill spares

20.Adapter

ACE Part No OEM REFF NO
251105 9000 0345 00
Rock drill spares

21.Washer

ACE Part No OEM REFF NO
251110 3115 1045 00
Rock drill spares

22.Throttle valve

ACE Part No OEM REFF NO
251115 3121 0349 00
Rock drill spares

23.Backhead

ACE Part No OEM REFF NO
251120 3115 0569 00
Rock drill spares

24.Main Valve

ACE Part No OEM REFF NO
252010 3106 8681 00
Rock drill spares

25.Bush for Cover

ACE Part No OEM REFF NO
252015 3100 9894 01
Rock drill spares

26.Valve Cover

ACE Part No OEM REFF NO
252020 -
Rock drill spares

27.Guide pin

ACE Part No OEM REFF NO
252025 3100 9665 00
Rock drill spares

28.Pawl Spring

ACE Part No OEM REFF NO
253010 3100 9140 02
Rock drill spares

29.Pawl Pin

ACE Part No OEM REFF NO
253015 3100 9641 01
Rock drill spares

30.Pawl

ACE Part No OEM REFF NO
253020 3101 3159 00
Rock drill spares

31.Rifle Bar

ACE Part No OEM REFF NO
253025 3101 3154 00
Rock drill spares

32.Pin - Ratchet Ring

ACE Part No OEM REFF NO
253030 0108 1336 00
Rock drill spares

33.Ratchet Ring

ACE Part No OEM REFF NO
253035 3106 8682 00
Rock drill spares

34.Guide Disc

ACE Part No OEM REFF NO
254010 3106 8683 00
Rock drill spares

35.Conical Nut

ACE Part No OEM REFF NO
254015 3006 8734 00
Rock drill spares

36.Lever Outlet Valve

ACE Part No OEM REFF NO
254020 3115 0577 00
Rock drill spares

37.Elastic Pin

ACE Part No OEM REFF NO
254025 0108 3330 00
Rock drill spares

38.Spring - Outlet Valve

ACE Part No OEM REFF NO
254030 3121 0338 00
Rock drill spares

39.Outlet valve

ACE Part No OEM REFF NO
254035 3115 1778 00
Rock drill spares

40.Cylinder

ACE Part No OEM REFF NO
254040 3121 0337 00
Rock drill spares

41.Rifle Nut

ACE Part No OEM REFF NO
254045 3100 9299 05
Rock drill spares

42.Piston

ACE Part No OEM REFF NO
254050 -
Rock drill spares

43.Intermediate Part

ACE Part No OEM REFF NO
254055 3121 0339 00
Rock drill spares

44.Chuck Nut

ACE Part No OEM REFF NO
254060 3115 1221 00
Rock drill spares

45.Rotation Chuck

ACE Part No OEM REFF NO
254065 -
Rock drill spares

46.Chuck Bushing

ACE Part No OEM REFF NO
254047 3121 0023 00
Rock drill spares

47.Fronthead

ACE Part No OEM REFF NO
255010 3121 0342 00
Rock drill spares

48.Buffer Plate

ACE Part No OEM REFF NO
255015 3121 0029 00
Rock drill spares

49.Rubber Buffer

ACE Part No OEM REFF NO
255020 3121 0030 00
Rock drill spares

50.Tension Pin

ACE Part No OEM REFF NO
255025 0108 3392 00
Rock drill spares

51.Retainer Pin

ACE Part No OEM REFF NO
255030 3121 0852 00
Rock drill spares

52.Retainer

ACE Part No OEM REFF NO
255035 3121 0851 00
Rock drill spares

A (10-11).Side Bolt Set 2 side Bolt 2 Dome Nut

ACE Part No OEM REFF NO
255040 -
Rock drill spares

B (1 to 5, 13 to 17,20 to 23, 35).Backhead Complete

ACE Part No OEM REFF NO
255045 -
Rock drill spares

C (24-26).Cover Complete

ACE Part No OEM REFF NO
255050 3106 8680 80
Rock drill spares

D (28-30).Pawl Complete (4 NOS. Each)

ACE Part No OEM REFF NO
255055 3115 9200 90
Rock drill spares

E (35-40).Cylinder Assembly

ACE Part No OEM REFF NO
255060 -
Rock drill spares

F (34-43).Cylinder Complete

ACE Part No OEM REFF NO
255065 -
Rock drill spares

G (41-42).Piston Complete

ACE Part No OEM REFF NO
255070 3100 8478 80
Rock drill spares

H (44-46).Rotation Chuck Complete

ACE Part No OEM REFF NO
255075 3121 0769 80
Rock drill spares

I (47-52).Fronthead Complete

ACE Part No OEM REFF NO
255080 -
Rock drill spares

J (48,49,51 (1 nos) & 50 (2 nos).Retainer Pin Set

ACE Part No OEM REFF NO
255085 -
